(AS/NZS 1429.1) 3.8/6.6kV, 6.35/11kV, 12.7/22kV, 19/33kV three-core shielded, PVC-sheathed aluminum core cable

These cables are mainly used for the supply of electricity with a supply frequency between 49 Hz and 61 Hz at the rated voltage, for fixed applications in wiring installations, power stations, but also for outdoor installations in areas where the underground is susceptible to mechanical damage.

AS/NZS 1429.1

Conductor: Circular compression type aluminum conductor according to AS/NZS 1125.

Maximum continuous operating temperature: 90°C

Conductor shield: Extruded semiconductor material, bonded to the outside of the insulation and operated in the same application as the insulation

Insulation: Cross-linked polyethylene (XLPE) - standard

Ethylene Propylene Rubber (EPR) - Alternative

Insulating Shield: Extruded semiconductor material

Metal Shield: Annealed Copper Wire: 3kA/1 sec (light load)

Annealed copper wire: 10kA/1sec (heavy load)

Jacket: Black 5V-90 polyvinyl chloride (PVC) - standard

Orange 5V-90 polyvinyl chloride (PVC) inner jacket with black HDPE outer jacket - alternative

Low Smoke Non-Halogen (LSOH) - Alternative
