（CE & RoHS） Rubber Submersible Pump Waterproof Cable H07RN-F

Suitable for use in turbines and fixed installation towers in wind power plants or other similar applications. The cable is compatible with the wind power plant. Can be used in onshore and offshore wind farms in wind power equipment.

-Excellent resistance to oil, acids, chemicals, water, ozone, extreme temperatures, cuts, tears and abrasion.

-Resistance to torsion (10,000 torsions at 1440° ambient temperature, 2,000 torsions at low temperature).

-Oil resistance (100°C, 24h).

-Resistant to artificial weathering (1008h) irradiation

-Salt spray resistance (336h)

-RoHS

2014/35/EU-Guideline ("Low Voltage Directive")CE

-Customized products are available for special constructions, other sizes, core and jacket colors.

Conductor material: Bare copper stranded wire

Conductor class: DIN VDE 0295 Class 5, cf. IEC 60228 Class 5

Insulation: Cross-linked elastomer compound type E14

Core marking: 5 more colored wires according to VDE 0293-308, from 6 black wires with white numbers, with or without GNYE

Stranding: Stranded in layers

Sheath: Cross-linked elastomer mix type EM2

Sheath Color:Black

Rated voltage: Uo/U: 450/750 V

Test voltage: 2.5KV

Minimum bending radius fixed laying value: to DIN VDE 0298 part 3

Minimum bending radius moving laying value: to DIN VDE 0298 part 3

Operating temperature fixed value: -40°C/+90°C

Flame retardant: according to IEC 60332-1

Standard: EN 50525-2-21
