（SAA）0.6/1KV Copper core PVC sheathed and insulated armoured control cable

The cable is used for non-enclosed control circuits and can be laid in ducts, direct burials or underground pipe installations in commercial, industrial, mining and power systems where mechanical damage may occur.

 SAA certification

flame retardant in accordance with IEC 60332-1-2

AS/NZS 5000.1 AS/NZS 3008 AS/NZS 1125

RoHS

2014/35/EU-guidelines (Low Voltage Directive) CE

Conductor material: bare copper wire

Conductor grade: IEC 60228 cl.5

Core insulation: PVC V-90

Core identification: white   black   red   yellowish green

Inner sheath: PVC

Armouring: galvanised steel wire armouring

Outer sheath PVC 5V-90

Outer sheath colour: orange （other colours are also available)

Rated voltage: 0.6/1kV

Test voltage: 4kV

Conductor resistance: in accordance with ASNZS1125 standard

Minimum bending radius fixed laying value: 7.5x d

Minimum bending radius moving laying value: 15x d

Operating temperature fixed small / large value: -15℃ / +90℃

Temperature class moving small/large value: -5℃+90℃

Flame retardant grade: self-extinguishing Conforms to IEC 60332-1

Standard: AS/NZS 5000.1
