（CE＆RoHS） H05RNH2-F CE Certified Rubber Flat Cable

Rubber sheathed cables for medium mechanical requirements. For connecting hand-held electrical equipment in homes and offices. Suitable for dry, wet and humid indoor and outdoor use.

-Flame retardant according to IEC 60332-1-2

-Oil resistance according to EN 60811-404

-H2: 2 cores, flat cable

-RoHS

 2014/35/EU-guideline "Low Voltage Directive") CE

-Customized products for special constructions, other sizes, core and jacket colors are available.

Conductor material: Bare copper stranded wire

Conductor class: Class 5/6 according to DIN VDE 0295, cf. IEC 60228 Class 5/6

Insulation: Cross-linked elastomer compound type EI4

Core identification: to DIN VDE 0293-308 with or without GNYE

Stranding: Stranded in layers

Sheath: Cross-linked elastomer compound type EM2

Sheath color: black

Rated voltage: Uo/U:300/500V

Test voltage:2KV

Minimum fixed bending radius: according to DIN VDE 0298 part 3

Minimum moving bending radius: to DIN VDE 0298 part 3

Operating temperature min./max.： -40°C/+90°C

Flame retardant standard: self-extinguishing and flame retardant according to IEC 60332-1

Standard: EN 50525-2-21
