（CE＆RoHS） Mining Rubber Cable MCP NTSWOEU 0.6/1KV

The cables are used for the connection of mobile machinery under very high mechanical loads, especially suitable for mining environments, also by means of guiding pulleys (gondolas) or as reel cables (LHD), and can withstand extremely high bending forces, high tensile strengths, shock and crush loads.

-Flame retardant according to EN 60332-1-2; IEC 60332-1-2.

-Abrasion and tear resistance, oil and ozone resistance.

-Customized products are available for special structures, other sizes, core and jacket colors.

-RoHS

2014/35/EU-guidelines (Low Voltage Directive) CE.

Conductor: DIN VDE 0295 class 6 flexible multi-stranded copper conductor.

Conductor type: IEC 60228 class 5 multi-stranded tinned copper conductor or DIN VDE 0295 class 5 flexible multi-stranded tinned copper conductor.

Insulation: EPR

Core (optional): special conductors, braided tinned copper and galvanized steel wire.

Inner jacket: Type GM1 rubber.

Armor/Ground Conductor: Combination copper-wire braid for both concentric ground and tensile armor.

Sheath: Type 5GM5 ammonia rubber, abrasion and tear resistant, oil resistant, flame retardant.

Rated voltage: 0.6/1kV

Conductor resistance: in accordance with IEC 60228 standard.

Temperature rating Fixed: -40°C/+90°C

Temperature rating Mobile: -15°C/+90°C

Flame rating: IEC 60332-1-2

Standard: VDE0250 Part 813
