(IEC 60228 Cl-1/2) 6241B/6242B/ 6243B (BS 7211) Copper Core Cable

This cable is suitable for fixed installations, especially for wiring indoor surfaces with low smoke emissions, wiring of sockets and lighting where there is a potential danger caused by fire, smoke emissions and toxic gases, and also in dry or damp environments, mounted on walls, panels or trays, in channels or embedded in plaster. Where mechanical protection is required it should be laid in ducts or raceways.

- Multi-strand flexible bare copper conductor

- Complies with IEC 60228 Cl-1/2

- Cross-linked polyolefin EI5/GP 8 insulation

- Cores and uninsulated circuit-protecting conductors are arranged in parallel.

- 2 cores, the circuit protection conductor is placed between the two cores, side by side in the center of the cable

- 3 cores, circuit protection conductor between black and gray cores

- LSOH jacket, LTS 2, white

Core colors

2 cores: brown, blue / 2 × 1.0 and 2 × 1.5 cores, brown, brown

3 cores: brown, black (centerline), gray

Technical characteristics

- Operating voltage: 300/500 V

- Test voltage: 2000 V

- Dynamic bending radius: 15 x OD

- Static bending radius: 10x OD

- Operating temperature at application: +5º C to +90º C

- Temperature at short circuit: +250º C

- Insulation resistance: 10 MΩxkm

- Halogen free according to EN 50267-2-1 / IEC 60754-1

- Smoke density according to EN 50268-2 / IEC 61034-2

- Toxic gas test according to EN 50267-2-2, IEC 60754-2

- Flame retardancy according to EN 50265-2-1, IEC 60332-1
