Unit lead-in cables (BS 6195-4) Industrial cables
Unit lead-in cables (BS 6195-4) Industrial cables
This cable is used as a power cable to permanently connect coil wound motors, panel wiring and electrical machinery. High temperature resistant and can be immersed in varnish. It can also be used for automotive wiring. The HOFR jacket is oil and varnish resistant and the multi-stranded conductor ensures both flexibility and positional stability when the cable is in use, and can be used as an alternative to three-phase and two-phase cables in some applications.
- Multi-strand flexible bare copper conductor
- Compliant with BS 6360 Cl-5/IEC 60228 Cl-5
- PETP barrier tape
- Ethylene Propylene Rubber - heat, oil and flame retardant insulation, ype FR1 (4A & 4C) & FR2 (4D & 4E&4F) to BS 7655.
- CSP (Chlorosulfonated Polyethylene), HOFR (Heat, Oil & Flame Resistant) Jacket ~ BS 6899, Black
- Operating voltage: Class 4A: 300/500V
Category 4C: 600/1000V
Category 4D: 1900/3300V
Category 4E: 3800/6600V
Category 4F: 6350/11000V
- Minimum Bend Radius: 4x O.D.
- Operating temperature: -20º C to +90º C
