(BS 6360 Cl-5, IEC 60228 Cl-5) 318B (BS 6500) copper core industrial cable

This cable is suitable for installation in public places such as hospitals and airports for chandelier applications or for use as a general power cable This cable is low smoke and halogen free and is suitable for use in environments where low smoke and halogen free conditions are required in case of fire. 318B is equivalent to EC standard H05Z1Z1-F.

- Multi-strand flexible bare copper conductor

- Complies with BS 6360 Cl-5/IEC 60228 Cl-5

- Halogen free thermoplastic compound TI6 insulation

- Yellow-green ground wire (3 cores and more)

- Halogen free thermoplastic compound TM7 jacket

Core colors

2 cores: brown, blue

3 cores: brown, blue and yellow-green

4 cores: brown, gray, black and yellowish green

5 cores: brown, blue, gray, black and yellowish green

Technical characteristics

- Operating voltage: 300/500 V

- Test voltage: 2000 V

- Dynamic bending radius: 6 x outer diameter

- Bend radius for fixed installations: 4x O.D.

- Operating temperature: -30º C to +90º C

- Temperature at short circuit: +160º C

- Insulation resistance: 20 MΩxkm

- Halogen free according to EN 50267-2-1 / IEC 60754-1

- Smoke density according to EN 50268-2 / IEC 61034-2

- Toxic gas test according to EN 50267-2-2, IEC 60754-2

- Flame retardancy according to EN 50265-2-1, IEC 60332-1
